Power Distribution Units (PDUs) are critical components for managing and distributing electrical power in various settings, including data centers, industrial facilities, and power conditioning applications.
With a range of PDUs available, from standard configurations to advanced models equipped with high-end features, these units cater to the diverse needs of different industries. They are engineered for reliability, precision, and efficiency, ensuring that power is distributed safely and effectively to all connected equipment.
PDUs come with customizable options such as capacity ranges up to 600kVA, advanced metering solutions, and robust protection features, making them suitable for a variety of applications. Whether it’s for a data center’s UPS output or a complex industrial setup, PDUs are designed to meet the rigorous demands of today’s power management systems.
Standard Technical Specifications
| Feature | Details |
| Capacity Range | Supports capacities up to 600kVA |
| Operating Voltage | Configurable to 415:415 or as per specified voltage requirements |
| Incomer Options | Available with Isolators, MCCB, ACB, or HRC Fuse systems |
| Metering Options | Includes options for Multifunction Meters, Load Managers, LED/LCD Displays, and Advanced Power Quality Analyzers |
| Transformer Configurations | Available in Delta-Star (Dyn11) and Delta-ZigZag Star (Dyn11) configurations |
| K-Rating | Optimized for K13 or K20 ratings, ideal for managing non-linear loads |
| Electrostatic Shielding | Incorporates Copper or Brass Foil/Mesh between windings for enhanced protection |
| Temperature Monitoring | Equipped with temperature sensors and monitoring systems |
| Outgoing Protection | Provides Isolators, MCCB, ACB, or HRC Fuse systems |
| Status Indication | Solid state indicators for ON/OFF/TRIP states, with optional Power Factor Correction (PFC) |
| Distribution Options | Offers MCBs with D-Curve characteristics, available in 1, 2, 3, or 4 poles |
| Hot Swap Feeders | Includes hot-swappable feeder arrangements for seamless maintenance |
| Bus Bar Construction | Features solid copper bus bars with appropriate ratings |
| Cooling Mechanism | Natural air cooling for loads <60kVA, with forced air cooling for higher capacities |
| Cooling Type | Supports both suction and throw cooling modes |
| Surge Protection | Options for Surge Protection Devices (SPD) in Class C, Class B+C, or Class B (Type 1, Type 2) |
| Maintenance Bypass | Equipped with a manual changeover switch for safe bypassing during maintenance |
| Earth Fault & Leakage Detection | Monitored through Earth Fault Relays (EFR) |
| Inrush Current Limiting | Available with manual or automatic soft starters |
| Panel Enclosure | Precision-engineered enclosures available in CNC-machined box type, load-bearing member type, or compartmentalized designs |
| Ingress Protection | Enclosures offer up to IP40 rating for ingress protection |
| Fan Failure Alert | Integrated fan failure detection with audible and visual alarms |
| Bus Bar Material | Constructed with copper or aluminum, based on application requirements |
| Power Cabling | Includes pre-configured power harnesses within the panel |
| Branch Circuit Monitoring | Branch Circuit Power Monitoring (BCPM) with Modbus RTU, Ethernet, or TCP-IP interfaces |
| Human-Machine Interface (HMI) | Equipped with LCD screens to display BCPM parameters |
| Software | Operable via standalone software for detailed monitoring and control |
Intelligent Secondary Power Distribution for Modern Data Centres
As data centres continue to scale, the need for flexible, intelligent, and highly reliable secondary power distribution becomes increasingly critical. The Remote Power Panel (RPP V3) extends power distribution closer to the IT load, enabling safe, efficient, and scalable power delivery from the PDU to individual server racks.
Designed for high-density data centre environments, the RPP V3 combines advanced protection, comprehensive branch circuit monitoring, and seamless integration with Energy and Building Management Systems, providing complete visibility over power usage while maximizing operational uptime. (ABB Library)
